CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch

Name: CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch
Brand: Rich or OEM
Price: 12 USD

China CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch wholesale

Brand Name : Rich or OEM

Model Number : CJ20

Certification : CE/CB/CCC

Place of Origin : China

MOQ : 5 pcs

Price : $12-$150

Payment Terms : T/T, Western Union, MoneyGram, L/C, D/A, D/P

Supply Ability : 50000 pcs per month

Delivery Time : 3-20 days

Packaging Details : Standard Export Package or according to customs request

Type : CJ20 series

Number of Pole : 3

Phase : 3

Main Circuit Rating Current : 63A -630A

Main Circuit Rating Voltage : 24-380v

Material of contact kit : Silver

Rated frequency : 50/60Hz

Mechanical life : 10,000,000 times

Contact Now

CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch

Application

CJ20 series AC contactors are suitable for frequency 50Hz,rated voltage up to 660V,rated current up to 630A,It is mainly used for making or breaking electric circuits at a long distance & for frequent starting & stopping, controlling AC motors.It is used in combination with thermal relay to compose a magnetic motor starter.The product accords with such standards as IEC60947-4-1 & GB1404

Specification

Type	Rated insulation voltage (V)	Rated thermal current (A)	Control power under AC-3 use category Pe Kw
Type	Rated insulation voltage (V)	Rated thermal current (A)	220V	380V	660V	1140V
CJ20-10	690	10	2.2	4	4	-
CJ20-16		16	4.5	7.5	11	-
CJ20-25		32	5.5	11	13	-
CJ20-40		55	11	22	22	-
CJ20-63		80	18	30	35	-
CJ20-100		125	28	50	50	-
CJ20-160		200	48	85	85	-
CJ20-160/11	1140	200	-	-	-	85
CJ20-250	690	315	80	132		-
CJ20-250/06		315	80	132	190	-
CJ20-400		400	115	200	220	-
CJ20-630		630	175	300	-	-
CJ20-630/06		630	175	300	350	-
CJ20-630/11	1140	400	-	-	-	400

CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch

Packaging & Shipping

1. We will ship the items within 3-15 working days after the payment is reached.

2. All the goods will be packed in export carton or wooden case carefully. We will make sure all product is compete when it arrive. We guarantee that all the packaging is intact when it reaches its destination .

3. The package will be shipped by sea or by air, or by TNT, DHL, FedEx, UPS, EMS or your forwarder . Please inform us directly which method is your preferred way .

CJ20 400A high power contactor magnetic contactor for industrial control 3 poles ac Electrical Contactor Switch

FAQ

Q: Does Richuang a factory or trading company?

A: Richuang is a factory that produces ranging from the low-voltage electric products. We have a competitive price on the market. We also have am import and export company

Q: What’s the delivery time when a customer has an order?

A: It is according to the quantity and the product, usually, the goods will be delivered within 2-3 weeks after placing an order.

Q: What is the warranty for each product?

A: Usually the warranty is two-year for low-voltage electrical products.

Q: How about The shipment terms?

A: FOB C&F CIF

Q: How about The payment terms?

A: Usually we accept TT 30% deposit in advance, 70% balance against the copy of B/L or before the shipment.

Q: What is the MOQ?

A:1. The sample order has no MOQ requirements.

2. First-order should be 1,000 USD and the quantity according to the products.

Q: What kind of orders were received by Richuang?

A: OEM, ODM, and special requirements are accepted.
